******Description:******
0.6-0.8um Micro grain size solid carbide Aluminum end mill 2 Flute
Type
No Coating
Made by 5 AXIS CNC grinder
Checked by Zoller Inspection Equipment
Workpiece upto HRC50
Standard Type
| Type | Square end mill, End Mills for Aluminum |
| Material | Carbide |
| Flutes: | 2 Flutes, 3 Flutes, |
| Hardness: | HRC50 |
| Helix Angle: | 45 and 55 |
| CoatingCoating: | No Coating |
| Size: | Dia: 1-20 mm, Overal Length:50-150mm |
| Smooth Finish: | Highly Polished |
| Feature: | Excellent chip evacuation |
| Measurement: | Metric |
| Stock: | For standard, have enough in stock |
| For non-standard, need to be customized |
| Nonstandard order: | Customize as request |
| Packing: | Can laser printing your logo and packing with your label |
| Suitable for Aluminum |
Advantage: - Meet quality specifications.
- Have technical ability and knowledge.
- Communicate precisely.
- Offer competitive prices.
- Believe in honest dealing.
- Provide needed information as and when required.
- Can deliver quickly in an emergency.
- Deliver when promised.
- Advise of potential trouble
|
Specifications:
| Order No | Cutting | Cutting Length | Shank | AOL |
| d | l | D | L |
| 1.0×3×4D×50L×2F×45º | 1 | 3 | 4 | 50 |
| 1.5×4×4D×50L×2F×45º | 1.5 | 4 | 4 | 50 |
| 2.0×6×4D×50L×2F×45º | 2 | 6 | 4 | 50 |
| 2.5×8×4D×50L×2F×45º | 2.5 | 8 | 4 | 50 |
| 3.0×8×4D×50L×2F×45º | 3 | 8 | 4 | 50 |
| 3.5×10×4D×50L×2F×45º | 3.5 | 10 | 4 | 50 |
| 4.0×11×4D×50L×2F×45º | 4 | 11 | 4 | 50 |
| 3.0× 8×6D×50L×2F×45º | 3 | 8 | 6 | 50 |
| 3.5×10×6D×50L×2F×45º | 3.5 | 10 | 6 | 50 |
| 4.0×11×6D×50L×2F×45º | 4 | 11 | 6 | 50 |
| 4.5×13×6D×50L×2F×45º | 4.5 | 13 | 6 | 50 |
| 5.0×13×6D×50L×2F×45º | 5 | 13 | 6 | 50 |
| 5.5×13×6D×50L×2F×45º | 5.5 | 13 | 6 | 50 |
| 6.0×15×6D×50L×2F×45º | 6 | 15 | 6 | 50 |
| 7.0×16×8D×60L×2F×45º | 7 | 16 | 8 | 60 |
| 8.0 ×20×8D×60L×2F×45º | 8 | 20 | 8 | 60 |
| 9 ×20×10D×75L×2F×45º | 9 | 20 | 10 | 75 |
| 10×20×10D×75L×2F×45º | 10 | 25 | 10 | 75 |
| 11×25×12D×75L×2F×45º | 11 | 25 | 12 | 75 |
| 12×30×12D×75L×2F×45º | 12 | 30 | 12 | 75 |
| 14×35×14D×100L×2F×45º | 14 | 35 | 14 | 100 |
| 16×40×16D×100L×2F×45º | 16 | 40 | 16 | 100 |
| 18×45×18D×100L×2F×45º | 18 | 40 | 18 | 100 |
| 20×45×20D×100L×2F×45º | 20 | 45 | 20 | 100 |
We also supply other Aluminum end mills:
we also accept customized size by order
| Why choose INMIND TOOLS |
Products Advantage: 1.Offer latest design and product information. 2. Carbide end mills with competitive price. 3. Germany and Austrilia 5AXIS grinder with top quality. 4. All our productions are used by best material. 5. Small MOQ: Small quantity order is also accepted
Factory Advantage: 1.Rich over 10 years production experience 2.Fast delivery and competitive lower freight charge 3.SGS certificate assure you our good quality 4.Strictly Quality Control in Factory
Quality & Inspection
1.More than 10 process,
2.Finished goods go through 3 strick inspection
3.All goods 100% pass on checking Our team ensure to produce perfact goods by heart!!! |
Our Advantages:
1) Competitive price
we are the mamufacturer, so we can supply the materials directly,
saving the agent fees and reducing the cost for you, we can make
sure the price is competitive.
2) The latest delivery time
new samples from the customer can be make out in 3-7 days.
mass production can be finished in 7-15 days according to order
quantity after receive deposit.
3) High quality contorl
we have the professional QC system, whats more, we have careful
workers to check the products one by one, so that we can make sure
the products with high quality.
4) Supreme after-sale services
For samples, we can adjust samples acording to every special
customer's request by adjusting the material, craftwork, accessory
etc, in order to meet the demands;for bulk production products, if
there is any problem, pls feel free to tell us, we'll solve it
without any delay.
5) Others
Different styles or small orders also can be produced, your own
designs are also welcomed.
Label & package: the same as customers requirements.
.
Our Services
Basic Services
ª One-stop shopping
ª Quality inspecting: 100% full inspection before delivering.
ª Tens of thousands of designs for you to choose from.
ª Quickly updated products
Customized Services
ª Professional Developmet Team will design new items to meet your
fashion development.
ª Ref. the Packing & Shipping, customized requirement is also
avaliable.
After-sale Services
When you receive the products,if any problem, pls feel free to
contact us. We are sure that any issue will get a prompt attention
and solution. And we never let it happen next time.
Client Voice
We are honored to hear from you. Any suggestion you provide will
promote our working passion and give us great encouragement.
Ordering Produres
- send me your artwork to quote,
- after confirm the price, we will make the artwork for you approve,
- approved the artwork
- pay the 30% deposit, then make the sample
- take pictures for your check the sample quality,
- after approve sample, arrange make the bulk
- payment 70% balance payment
- send the labels to your required address
- feedback from your for further orders
Contac us----24 Hours service
INMIND TOOLS
Head office (patrick.yin +86-13801503379)
Whatsapp/Wechat:+86-1801792622, QQ:4102512
TEL : 86-519-8343 3961| FAX: 86-519-8343 3775 | Website: www.inmind.com.n or www.inmind.cn
Address: No.35 Weishanhu Road, Xixiashu Town,Changzhou, Jiangsu,
China(213135)
