******Description:******
| Coating Paramter |
| Item | ALTiN | TiALN | TiSiN | BALINIT@ ALCRONA PRO |
| Hardness(HV) | 3200 | 2800 | 3600 | 4000 |
| Thickness(UM) | 2.5-3 | 2.5-3 | 3 | 3 |
| Oxidation | 900 | 800 | 1000 | 1200 |
| Friction | 0.3 | 0.3 | 0.45 | 0.4 |
| Colour | Black | Purple | Copper | Black |
| The name of product | Solid Carbide End Mills & Tungsten Carbide HRC55 Corner Radius End
Mill |
| Type | solid carbide R endmills,solid carbide flattened endmills solid carbide ball nose endmills |
| Model Number | Various |
| Helix angle | 35 °,45° |
| Place of Origin | China (Mainland) |
| Usage | Milling cutter |
| Advantage | Best quality along with reasonable prices |
| HRC | 45°,55°,65° |
| Brand Name | INMIND |
| Material | Tungsten Carbide |
| Coating | AlTiN,TIALN,TISIN |
| Free sample | Yes |
| OEM&ODM | Acceptable |
| The label of product | According to customer designation |
| Min.Order Quantity | 10 Piece/Pieces |
| FOB Price | Send an inquiry |
| Term of delivery | within one week, depends on inventory |
| Payment Ways | T/T,WEST UNION,PAYPAL,Alipay. |
Quick Detail
0.5-0.6um Ultra-Fine grain size solid carbide Corner radius end
mill
SiN(Copper),
BALINIT@ X.CEED
Made by 5 AXIS CNC grinder
Checked by Zoller Inspection Equipment
Workpiece upto HRC55
Standard Type
CB-Ceratizit WF25 Carbide Rods
Specifications:
| order number | Cutting | Cutting Length | Shank | R Corner | AOL |
| d | l | D | R Corner | L |
| 10×25×10D×R2.0×75L×4F | 10 | 25 | 10 | R2.0 | 75 |
about the corner,we supply from R0.1 to R3.0 for 10mm Corner Radius
end mills
we also supply the other size of corner radius endmill(1mm to 12mm)
| order number | Cutting | Cutting Length | Shank | R Corner | AOL |
| d | l | D | R Corner | L |
| 1×3×4D×R0.1×50L×4F | 1 | 3 | 4 | R0.1 | 50 |
| 1×3×4D×R0.2×50L×4F | 1 | 3 | 4 | R0.2 | 50 |
| 1.5×3×4D×R0.2×50L×4F | 1.5 | 4 | 4 | R0.2 | 50 |
| 1.5×3×4D×R0.3×50L×4F | 1.5 | 4 | 4 | R0.3 | 50 |
| 2×6×4D×R0.2×50L×4F | 2 | 6 | 4 | R0.2 | 50 |
| 2×6×4D×R0.3×50L×4F | 2 | 6 | 4 | R0.3 | 50 |
| 2×6×4D×R0.5×50L×4F | 2 | 6 | 4 | R0.5 | 50 |
| 2.5×8×4D×R0.2×50L×4F | 2.5 | 6 | 4 | R0.2 | 50 |
| 2.5×8×4D×R0.5×50L×4F | 2.5 | 6 | 4 | R0.5 | 50 |
| 3×8×3D×R0.3×50L×4F | 3 | 8 | 3 | R0.3 | 50 |
| 3×8×3D×R0.5×50L×4F | 3 | 8 | 3 | R0.5 | 50 |
| 3×8×4D×R0.3×50L×4F | 3 | 8 | 4 | R0.3 | 50 |
| 3×8×4D×R0.5×50L×4F | 3 | 8 | 4 | R0.5 | 50 |
| 4×10×4D×R0.5×50L×4F | 4 | 10 | 4 | R0.5 | 50 |
| 4×10×4D×R1.0×50L×4F | 4 | 10 | 4 | R1.0 | 50 |
| 4×10×6D×R0.5×50L×4F | 4 | 10 | 6 | R0.5 | 50 |
| 4×10×6D×R1.0×50L×4F | 4 | 10 | 6 | R1.0 | 50 |
| 5×13×6D×R0.5×50L×4F | 5 | 13 | 6 | R0.5 | 50 |
| 5×13×6D×R1.0×50L×4F | 5 | 13 | 6 | R1.0 | 50 |
| 6×15×6D×R0.5×50L×4F | 6 | 15 | 6 | R0.5 | 50 |
| 6×15×6D×R1.0×50L×4F | 6 | 15 | 6 | R1.0 | 50 |
| 8×20×8D×R0.5×50L×4F | 8 | 20 | 8 | R0.5 | 60 |
| 8×20×8D×R1.0×50L×4F | 8 | 20 | 8 | R1.0 | 60 |
| 8×20×8D×R1.5×50L×4F | 8 | 20 | 8 | R1.5 | 60 |
| 10×25×10D×R0.5×50L×4F | 10 | 25 | 10 | R0.5 | 75 |
| 10×25×10D×R1.0×50L×4F | 10 | 25 | 10 | R1.0 | 75 |
| 10×25×10D×R1.5×50L×4F | 10 | 25 | 10 | R1.5 | 75 |
| 10×25×10D×R2.0×50L×4F | 10 | 25 | 10 | R2.0 | 75 |
| 12×30×13D×R0.5×50L×4F | 12 | 30 | 12 | R0.5 | 75 |
| 12×30×13D×R1.0×50L×4F | 12 | 30 | 12 | R1.0 | 75 |
| 12×30×13D×R1.5×50L×4F | 12 | 30 | 12 | R1.5 | 75 |
| 12×30×13D×R2.0×50L×4F | 12 | 30 | 12 | R2.0 | 75 |
we also accept customized size by order
Why Choose INMIND ?:
1.100% Manufacturer
We are professional manufacturer of carbide end mills with over 10 years
experience and we already do international market for more than 8 years.
2. Best material selection
All our goods are made of best materials which have the SGS
certificate from the best supplier.
And we have been certified by ISO9001 and ISO14001 environmental
management system.
3.Good service&Top quality
Most perfect equipment, capable&experienced Engineer and skilled workers, advanced production management experience and
strict quality management standard.
4. Quality control
Every single piece of product, every production, procedure is
inspected and controlled before
packing the goods into export carton. We ensure every of product
shipped are of good quality.
5. After sales service provided
Besides, after sales service is necessary for more understanding
for your needs. We do keep a
close concern.
Our service: How to order?
1 Customers send detailed inquiry to us by email
2 We reply with price, specifications, packing, photos, and other
details.
3 Both of us agree the price and confirm the details.
4 We write the proforma invoice and send to customers.
5 Customers make deposit.
6 We make mass production samples.
7 We send mass product samples or send photos to customers for
approval.
8 Customers confirm the mass production samples.
9 We start mass production.(we have huge stock for most standard
end mills)
10 We show ready products' photos or customers inspect on site.
11 Customers make balance payment.
12 Delivery is arranged. Feedback from customers for better work in
future.
Payment:
T/T ,Western Union, Paypal,Alipay,or the other ways
